specifications

Wireless specifications :

Communications

433

Communications

433 to 440MHZ

Transmission range

Transmission range

Data rate

10kbps

Memory

100, 000@13Byte barcode

Battery capacity

Battery capacity

Charging time

5H

The life time of the full charge

6h (continuous reading sitistion)

12h (Manual reading situation) More than

15 days (stand-by time)

Communication mode

Read-time mode/Inventory mode / Cache mode

Electrical Characteristics

Interface

USB HID KEYBOARD/USB VCP

Voltage requirement

5VDC ±5%

Current consumption

Max: 180mA

Optical Characteristics

Photo sensor

 CMOS array sensor

SENSOR RESOLUTION

640x480 pixels

Light source

5600K white LED

Aim light source

Aim light source

Performance Characteristics

Decode angle

Pitch angle: ±55°

Skew angle: ±55°

Tilt angle: ±180°

Min resolution

1D:5mil

2D:10mil

Min.PCS value

› 15%UPC/EAN 13 (13mil)

Field of View

40° (H) x29° (V)

Identification

1D: UPC-A,UPC-E,EAN-8,EAN-13,Code 39, Code 39,Code 128,Interleaved 2 of 5,Codabar,Vode93

2D: PDF417,MicroPDF417,Data Matrix,QR Code Micro QR, Aztec

Physical Characteristics

Dimensions

Scanner: 95mm x 70mm x 168mm (L x W x H)

Receiver: 55mm x 14mm x 8mm (L x W x H)

Weight

Scanner :186g Scanner: 186g

Receiver: 5g received: 5g

Environmental Characteristics

Temp

-20ºC to 60ºC C/-4° to 140° F((operation)) -40° -to 80° C/-40° to 176° F(storage)

Humidity

5-95% (operation) 5-95% (storage)

Shock drop test

1.5m drop onto concrete surface
